U-1000 R2V (industrial unarmoured)

Produits

U1000 R2V 2X25

Réf. Nexans 56416256700

  • Packaging: Drum (m)
  • Conductor cross-section: 25 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 2X35

Réf. Nexans 56416259100

  • Packaging: Drum (m)
  • Conductor cross-section: 35 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 2x1,5 XP

Réf. Nexans 56322211100

  • Packaging: Drum (m)
  • Conductor cross-section: 1,5 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 100 m



U1000 R2V 2x10 XP

Réf. Nexans 56322250000

  • Packaging: Drum (m)
  • Conductor cross-section: 10 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 2x16 XP

Réf. Nexans 56421252300

  • Packaging: Drum (m)
  • Conductor cross-section: 16 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 2x2,5 XP

Réf. Nexans 56322213200

  • Packaging: Drum (m)
  • Conductor cross-section: 2,5 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 90 °C
  • Length: 2000 m



U1000 R2V 2x4 XP

Réf. Nexans 56322215300

  • Packaging: Drum (m)
  • Conductor cross-section: 4 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 2x6 XP

Réf. Nexans 56322247100

  • Packaging: Drum (m)
  • Conductor cross-section: 6 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3G1,5 XP MOB

Réf. Nexans 56322311621

  • Packaging: Drum (m)
  • Conductor cross-section: 4 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3G2,5 XP MOB

Réf. Nexans 56322313721

  • Packaging: Drum (m)
  • Conductor cross-section: 6 mm²
  • Number of cores: 2
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3G4 XP

Réf. Nexans 56322315821

  • Packaging: Drum (m)
  • Conductor cross-section: 4 mm²
  • Number of cores: 3
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3X25

Réf. Nexans 56416356800

  • Packaging: Drum (m)
  • Conductor cross-section: 25 mm²
  • Number of cores: 3
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3X35

Réf. Nexans 56416359200

  • Packaging: Drum (m)
  • Conductor cross-section: 35 mm²
  • Number of cores: 3
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3x10 XP

Réf. Nexans 56322350021

  • Packaging: Drum (m)
  • Conductor cross-section: 10 mm²
  • Number of cores: 3
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3x16 XP

Réf. Nexans 56421352400

  • Packaging: Drum (m)
  • Conductor cross-section: 16 mm²
  • Number of cores: 3
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 3x6 XP

Réf. Nexans 56322347021

  • Packaging: Drum (m)
  • Conductor cross-section: 6 mm²
  • Number of cores: 3
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 4G1,5 XP CR

Réf. Nexans 56321411621

  • Packaging: Coil (m)
  • Conductor cross-section: 1,5 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 100 m



U1000 R2V 4G2,5 XP CR

Réf. Nexans 56321413721

  • Packaging: Coil (m)
  • Conductor cross-section: 2,5 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 2000 m



U1000 R2V 4G4 XP

Réf. Nexans 56322415421

  • Packaging: Drum (m)
  • Conductor cross-section: 4 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 4X10

Réf. Nexans 56315450021

  • Packaging: Drum (m)
  • Conductor cross-section: 10 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 4X25

Réf. Nexans 56416456000

  • Packaging: Drum (m)
  • Conductor cross-section: 25 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 4X35

Réf. Nexans 56416459300

  • Packaging: Drum (m)
  • Conductor cross-section: 35 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 500 m



U1000 R2V 4X6

Réf. Nexans 56315447821

  • Packaging: Drum (m)
  • Conductor cross-section: 6 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 4x16 XP

Réf. Nexans 56421452500

  • Packaging: Drum (m)
  • Conductor cross-section: 16 mm²
  • Number of cores: 4
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 5G1,5 mm² CR

Réf. Nexans 56314511221

  • Packaging: Coil (m)
  • Conductor cross-section: 1,5 mm²
  • Number of cores: 5
  • Max. conductor temperature in service: 85 °C
  • Length: 2000 m



U1000 R2V 5G10 XP

Réf. Nexans 56322550021

  • Packaging: Drum (m)
  • Conductor cross-section: 10 mm²
  • Number of cores: 5
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 5G2,5 mm² CR

Réf. Nexans 56314513321

  • Packaging: Coil (m)
  • Conductor cross-section: 2,5 mm²
  • Number of cores: 5
  • Max. conductor temperature in service: 85 °C
  • Length: 2000 m



U1000 R2V 5G25

Réf. Nexans 56416556121

  • Packaging: Drum (m)
  • Conductor cross-section: 25 mm²
  • Number of cores: 5
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 5G35

Réf. Nexans 56416556421

  • Packaging: Drum (m)
  • Conductor cross-section: 35 mm²
  • Number of cores: 5
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 5X16

Réf. Nexans 56416552600

  • Packaging: Drum (m)
  • Conductor cross-section: 16 mm²
  • Number of cores: 5
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



U1000 R2V 5x16 XP

Réf. Nexans 56421552600

  • Packaging: Drum (m)
  • Conductor cross-section: 16 mm²
  • Number of cores: 5
  • Max. conductor temperature in service: 85 °C
  • Length: 1000 m



Description

Description

Normes

  • Normes internationales
    IEC 60502
  • Normes nationales
    XP C 32-321

Application

U-1000 R2V cables can be used in all low voltage power installations. Multiconductors cables are adapted to remote control and telecontrol installations.

In case of high ambiant temperature, use correction coefficient.

Installation

These cables can be fixed on cable trays, within conduits or fixed to walls. They also can be buried directly with extra mechanical protection.

Cross sections 1,5 - 2,5 and 4 mm² have to be of class 2 flexiblility, if the cable is connected to equipment subject to vibration.

Caractéristiques

Caractéristiques

Construction characteristics

Construction characteristics

Conductor material
Bare copper
Insulation
XLPE (chemical)
Outer sheath
PVC
Sheath colour
Black
Conductor shape
Circular

Electrical characteristics

Electrical characteristics

Rated Voltage Uo/U (Um)
0.6/1 kV

Mechanical characteristics

Mechanical characteristics

Mechanical resistance to impacts
Good
Cable flexibility
Rigid

Usage characteristics

Usage characteristics

Short-circuit max. conductor temperature
250 °C
Operating temperature, range
-10 - 60 °C
Flame retardant
C2, NF C 32-070
Weather resistance
Very good
Chemical resistance
Accidental
Bending factor when laying
6 (xD)
